Product Details：

Cabinet design features
Welded frame combined design; light weight, strong structure, flexible and changeable; cabinets can be spliced and combined; front and rear doors can be interchanged left and right; opening angle >130 degrees, complete accessories.

Cabinet material information
Frame ≥ 1.5mm thick steel plate; vertical installation column ≥ 2.0mm thick steel plate; side plate ≥ 1.0mm thick steel plate; front door ≥ 1.2mm thick steel plate; top cover ≥ 1.0mm thick steel plate

Advantages

Significantly improve the space utilization rate of the computer room; the opening rate is ≥70%, up to 80%, reducing the occurrence of local hot spots; meeting the environmental requirements of various computer rooms; modular design, convenient installation.

Important features

Static load capacity can reach 1500kg, dynamic 1200kg; IP20 protection level; front and rear doors, side panels and top cover can be reliably grounded to the cabinet; adjustable horizontal feet at the bottom make the cabinet more stable; front and rear doors and side panels can be locked; shockproof Fixed design.

Product Features：

RACK series cabinets include not only a series of standard server cabinets for computer rooms and data centers, but also a series of dedicated large-capacity wiring cabinets, and a series of cabinets with high-end customized pure aluminum profile frames and high-protection industrial data centers. Cabinet series. In addition, it can also provide non-standard customized solutions to achieve non-standard fast delivery.

Product Composition：

It mainly includes frame, angle gauge, front and rear mesh doors, side panels, top panel, bottom caster level adjustment feet and 0U vertical cable management board, etc..
